Triple-Effect Engine: Integrates powerful beam, wash, and strobe functions into a single unit. The main light source comprises 5x60W quad-color (RGBA/W) LEDs for vibrant colors and intense beams/wash.
Advanced Strobe System: Features a dedicated strobe array with 35 high-power 3W white LEDs and 70 RGB LEDs, capable of fast flashing (1-25 times per second) and colorful strobe effects.
Precision Movement & Zoom: Equipped with 16-bit resolution for smooth 360° continuous pan (X-axis) and 360° tilt (Y-axis). The motorized zoom offers a wide range from a tight 4° beam to a 40° wash.
Professional Control & Flexibility: Supports DMX512 control with 26 or 68 channels and includes RDM (Remote Device Management) for easy setup. Offers multiple standalone modes: Sound Control, Master/Slave Synchronization, and built-in Auto Programs.
High Power & Built-in Macros: With a maximum power consumption of 450W and a wide voltage input (AC90-240V, 50/60Hz), it delivers high output. It comes pre-loaded with macro effects for strobe, color chases, and more.
Ideal Application Scenarios:
This all-in-one moving head is designed for professional entertainment venues and mobile setups that require powerful, versatile lighting in a compact format, such as:
Nightclubs, Bars, and Live Music Venues
Small to Medium-Sized Concert Stages and Touring Productions
Corporate Events, Wedding Receptions, and Private Parties
Theatre Productions and Fashion Shows
Fixed Installations in Multi-Purpose Event Halls
Personalities
DMX Channel: 26/68CH
Protocols: DMX,Auto,Sound,Master/Slave
Colors:
Color :RGBW 4in1 color mixing
Feature: Each main LED is controllable individually.white strobe LED 5 areas controllable individually, RGB 3-in-1 effect light 10 areas controllable individually. Unlimited Pan/Tilt movement to bring dynamic effects.
Working environment: indoor
Cooling system: fan forced cooling system
Effect macros:
0%-100% linear dimming
Strobe: 0-25times/second
LCD display screen
Pan: Unlimited rotation
Tilt: Unlimited rotation LED
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 450Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 18 Kg(39.68lbs)
Size: 21.08" x3.94" x 11.81" (L51x W10 x H30)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
RGBW Led |
|
Led |
5x60W |
|
Strobe Led |
35 x 3W white LED and 70 x 0.2W RGB 3IN1 LED |
|
LED life expectancy |
50000Hours |
|
Color Temperature |
7800K |
|
Photometric data |
|
|
Lens angle |
4-40° |
Product details
