Signature Innovation: The Dynamic Lens System.
Our patented rotatable front lens plate revolutionizes beam shaping. Spin effects directionally for hypnotic vortices, kaleidoscopic patterns, and textured layers that other lights canot achieve. Coupled with a 4.5° to 45° motorized zoom, go from a laser-tight beam to a sweeping wash in seconds. This is the versatility professionals demand.
Total Creative Command, Simplified Operation.
Choose your level of control: run it in Auto for instant impact, sync to music with Sound Active, or take full command via DMX512 with 23, 35, or 51-channel modes for deep programming. The intuitive color LCD screen with Banki buttons and pre-loaded K10 profile ensure quick setup and seamless integration into any existing rig.
Built for the Long Run.
With a 50,000-hour LED lifespan and robust universal power supply (AC100-240V), the K10 is a reliable investment that reduces maintenance and downtime. Its efficient design delivers maximum impact at 500W total draw.
Your Vision, Fully Realized.
This is more than lighting—it's storytelling. Whether you're designing for a concert tour, a high-energy nightclub, or a flagship corporate event, the K10 gives you the pixel-level control and dynamic effects to create truly iconic moments.
Stop imagining the perfect effect. Create it. Command the light with the K10.
Personalities
DMX Channel: 23/35/51CH
Protocols: DMX,Master/Slave,auto,sound
Colors:
Color:RGBW color mixing
Feature: Supports the rotation of the lens board to produce beam and bee-eye effects. A single lamp bead supports color individual control.
Equipped with CTO, dyeing, beam, effect modes (vortex, kaleidoscope), front mirror disc with variable direction and infinite rotation, single point control of light beads
Bigger shell size and better heat dissipation. Compare with other common model. This model outside size is bigger a lot. And more powerful.
Led display and back side main board use same cl-ay p-acky button and library is K10.
Effect macros:
0%-100% linear dimming
Strobe: 25seconds/time
LED display screen
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 270 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 500Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 11 Kg(24.25lbs)
Size: 18.11" x14.57" x 12.6" (L46 x W37 x H32)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
RGBW LED |
|
Power |
7x40W |
|
Ballast |
Electronic ballast |
|
LED life expectancy |
50000Hours(The bulb and reflector are packaged as a whole, with higher light efficiency and longer service life) |
|
Color Temperature |
7800K |
|
Photometric data |
|
|
Lens angle |
4.5°-45° |
Product details
