High-Output COB LEDs: 12x40W COB chips provide 600W total power, ensuring intense brightness and consistent beam quality for large venues.
Pixel Control & RGBW Color Mixing: Individual LED control enables detailed color patterns and smooth gradients, while the RGBW system offers rich colors and pure white light.
Versatile Optics: From a ultra-narrow 1.7° fixed lens to a adjustable 5°-35° zoom, it supports both long-throw beam effects and wide wash applications.
Segmented Focus Function: Allows customized focus zones for creative lighting designs, adding depth and dimension to performances.
Wide 220° Y-Axis Rotation: Maximizes coverage and dynamic movement for immersive lighting scenes.
Energy-Efficient Design: Optimized power distribution ensures high performance while reducing
operational costs.
Durable Construction: Built for rigorous use in commercial settings like clubs, stages, and architectural installations.
Ideal for professional lighting in clubs, concerts, and events, this moving head wash light combines power, precision, and flexibility to meet diverse creative needs.
Product advantages
The TP-L1240B's combination of ultra-narrow 1.7° beams and wide 35° wash coverage, coupled with 220° vertical movement and segmented focus, enables creative lighting designers to achieve both intimate atmospheric effects and large-scale visual impacts across various professional settings.
High-Output COB LEDs
Pixel Control & RGBW Color Mixing
Segmented Focus Function
Wide 220° Y-Axis Rotation
Energy-Efficient Design
Personalities
DMX Channel: 20CH/57CH
Protocols: DMX
Connectors: Locking 3 pin XLR IN/ OUT
Power connector: Power Twist In/Out
Colors
RGBW color mixing system, 16.7 million kinds of color change
Effect macros
Color change, color strobe, color dimmer, color gradual change/color jump change
Zoom range from 5°-35° (support 2 segment zoom one by one)
Dimmer/Strobe
Liner Dimmer: 0-100% linear dimmer
Strobe: 1 – 20Hz
LED display screen
DMX512/Auto/Master Slave/Sound Activated
Tilt: 220 degrees+ fine
Cooling system: fan forced cooling system
Led: pixel control
Housing
Aluminum die casting
Working environment: Indoor&outdoor
Electrical
Optical voltage: Ac100-240v,50/60 hz
Max power consumption: 600watt
Packaging
Carton box + foam shell
Flight case
Weight - size
Net weight: 33.07lbs(185kg)
Size: 43.34" x7.48" x 14.17" (l110x w19x h36)
Application scenarios
Product specification
|
Light source |
|
|
Source type |
RGBW LEDs |
|
Power |
12x40W |
|
LED life expectancy |
50,000 hrs |
|
Photometric data |
|
|
Led Range |
1.7° |
Product details
