This professional-grade moving head light delivers vibrant color mixing and dynamic beam effects, powered by 6 high-intensity 40W RGBW LEDs with a remarkable lifespan of up to 50,000 hours. Its core functionality centers on exceptional versatility and control. The motorized pan (540°) and tilt (180°) movements offer wide coverage with high, adjustable speed, while the motorized zoom function allows seamless beam angle adjustment from a tight 4° spot to a wide 36° wash.
Key features include flexible control via DMX512 (10/17 channels), Master-Slave, Auto-run, or Sound-active modes, all managed through an intuitive 2.4-inch LCD display. It supports creative beam shaping with a rotating lens effect and comes with 8 internal programs. Designed for easy integration, it features standard 3-pin XLR connectors for DMX and power linking, and an IEC-10A power input compatible with AC100-240V (consuming 280W). With a sturdy build (Net Weight: 9KG) and a mounting design suitable for both upright placement and inverted hanging, it is a reliable and efficient lighting solution.
Ideal Application Scenarios:
Stage Productions: Perfect for concerts, theaters, and live events for front, side, or back lighting, creating dramatic beam movements and color accents.
Club & Entertainment Venues: Ideal for disco bars, nightclubs, and live houses where sound-active mode and dynamic auto programs can energize the atmosphere.
Event Lighting: Suitable for weddings, corporate events, and fashion shows for highlighting stages, architectural elements, or creating aerial beam effects.
Fixed Installations: Can be used in churches, auditoriums, or themed spaces due to its long LED life and low power consumption, requiring minimal maintenance.
Mobile DJ Rigs: Its robust design, standard DMX control, and multiple operating modes make it a great choice for mobile DJs and rental companies.
Personalities
DMX Channel: 10/17CH
Protocols: DMX,Sound,Auto,Master/Slave
Colors:
Color:RGBW
8 internal program
Feature: this model support zoom function and lens can rotation to make colorful beam effect
Zoom: 4-36°
Effect macros:
0%-100% linear dimming, smooth without flicker
Strobe: 1-20times/second
LCD display screen
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 180 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 280Watt
Power connection: IEC-10A
Connection:3pin-XLR male/female
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 12 Kg(26.46lbs)
Size: 14.96" x16.93" x 11.81" (L38 x W43 x H30)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
High power RGBW Led |
|
Power |
6x40W |
|
Ballast |
Electronic ballast |
|
LED life expectancy |
50000Hours |
|
Color Temperature |
7800K |
|
Photometric data |
|
|
Lens angle |
4-36° |
Product details
Feel Free To Contact Us
