Professional 150W 3-in-1 LED Moving Head: Versatile High-Power Lighting for Indoor Stages
This all-in-one moving head combines wash, beam, and spot functions into a single, efficient fixture, engineered for dynamic performances and long-term reliability.
Triple-Function Output: Integrates Wash, Beam, and Spot effects in one robust fixture for maximum creative flexibility.
High-Efficiency LED Engine: Features a 150W high-brightness imported LED with a 75,000-80,000K color temperature and an ultra-long 80,000-hour lifespan, ensuring brilliant, consistent light with low maintenance.
Comprehensive Effects System:
Color: 7 colors + white, with smooth rainbow effects.
Gobos: 10 static gobos and 6 rotating gobos (with rotation & waterfall effects).
Prism: 3-facet rotating prism for multiplying and texturizing beams.
Precision Control & Movement:
18 DMX Channels for detailed parameter control.
Multi-Control Modes: DMX512, Master/Slave, Sound-Activated, and Automatic.
Wide & Accurate Pan/Tilt: 540° horizontal and 240° vertical scan range with 16-bit precision for incredibly smooth, silent movement.
Superior Optical Performance: 0-100% linear dimming and focus enable flawless, flicker-free transitions and sharp beam shaping.
Universal & Robust Design: Auto-sensing voltage (AC90-240V) for worldwide use. Compact, lightweight design (9kg) ensures easy integration and rigging.
Personalities
DMX Channel: 18CH
Protocols: DMX,Auto,Sound,Master/Slave
Colors:
Color wheel: 7 color plus open+rainbow effect
Fixed Gobo wheel: 10 pattern plus open
Prism lens: 3 facet prism,prism rotation
Focus:0-100% liner
Rotation gobo wheel:6 gobos +open,with rotation and running water efffect
Effect macros:
0%-100% linear dimming,
Strobe: 0.5-9Hz
LCD display screen
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 240 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 280Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 12 Kg(26.46lbs)
Size: 18.9" x14.57" x 14.17" (L48 x W37 x 36H)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
High brightness imported chip LED |
|
Power |
1x150W |
|
Ballast |
Electronic ballast |
|
LED life expectancy |
8000Hours |
|
Color Temperature |
7500K-8000K |
|
Photometric data |
|
|
Lens angle |
8-17° |
