This 200W LED moving head is an all-in-one lighting solution that combines beam, wash, and pattern capabilities. Its core functions are driven by a high-efficiency 7500K LED, ensuring brilliant white light and long service life. Key features include:
Comprehensive Motion: Wide 540° pan and 270° tilt ranges allow for extensive coverage and dynamic movement.
Advanced Optical System: Features motorized zoom (7-21°), a color wheel with 9 colors plus open, separate static and rotating gobo wheels for rich texture projection, a 4-facet rotating prism for multiplying effects, and a frost filter for softening the beam.
Flexible Control: Equipped with 18 DMX channels and supports multiple control modes (DMX512, Master-Slave, Auto, Sound-Active), making it suitable for both professional and semi-professional use.
Robust Design: Engineered with a high-performance aluminum heat dissipation structure to maintain brightness and longevity. The adjustable 180° LCD screen (Chinese/English) ensures convenient operation in any installation position.
Ideal Application Scenarios:
This versatile moving head light is perfect for a wide range of indoor and outdoor events requiring powerful, reliable, and feature-rich lighting, such as:
Live concerts, clubs, and DJ performances.
Theater productions and stage shows.
Event venues for weddings, corporate events, and parties.
Fixed installations in houses of worship, theaters, or entertainment complexes.
Personalities
DMX Channel: 18CH
Protocols: DMX,Auto,Sound,Master/Slave
Colors:
Color wheel: 9 color plus open+half color effect
Fixed Gobo wheel: 9 pattern plus open+rotation and running water effect
Rotation Gobo wheel : 7 pattern plus open
Prism: 4 facet prism with bi-direction rotating
Frost:with frost effect
Zoom angle:7-21°
Effect macros:
0%-100% linear dimming
Strobe: 1-25times/second
LCD display screen
Feature: new design led lamp aluminum heat dissipation part and support higher brightness.
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 270 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 350Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 23 Kg(50.71lbs)
Size: 13.78" x9.45" x 21.65" (L35 x W24 x H55)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
White led |
|
Power |
1x200W |
|
Ballast |
Electronic ballast |
|
LED life expectancy |
50000Hours |
|
Color Temperature |
7500K |
|
|
|
|
Zoom angle |
7-21° |
Product details
