High-Efficiency & Long-Life Engine: Utilizes a 150W high-output white LED with a 50,000-hour lifespan and low power consumption, providing exceptional brightness (3450 LUX @5m) and cost-effectiveness.
Intelligent Thermal Protection System: Features an auto-adjusting cooling system that activates fans at 40°C and automatically reduces brightness at 70°C to prevent overheating and extend fixture life—a critical advantage for prolonged use.
Comprehensive Creative Toolkit:
Full-Color & Gobo System: 7-color + white wheel, an 8-gobo static wheel, and a 6-gobo rotating wheel, all with variable-speed rotation and shake effects.
Multi-Faceted Prism: Equipped with a 3-facet prism that rotates bi-directionally at variable speeds for complex beam multiplication.
Dynamic Effects: Includes a high-speed strobe (1-25 flashes/sec) and internal programs for standalone operation.
Professional Control & Integration:
Multi-Protocol & Channel Flexibility: Controllable via DMX512 (selectable 16/14/12/10 channels), Master-Slave, Sound Activation, or Auto Mode.
User-Friendly Operation: Features a colorful LCD display for easy setup and monitoring.
Robust Connectivity: Includes POWERCON IN/OUT for power linking, 3-pin XLR DMX connectors, and two Omega Clamps for secure rigging.
Universal & Reliable Build: Supports wide voltage input (AC90-260V), operates with a low-noise cooling system, and has an IP20 rating for indoor use. Shipped in a carton box with an optional flight case for protection.
Personalities
DMX Channel: 10/12/14/16CH
Protocols: DMX,Sound,Auto,Master/Slave
Colors:
Color wheel:7color plus open+rotation with variable direction and speed
Fixed Gobo wheel: 8 gobos patterns +white, wheel rotation and shake
Rotation Gobo Wheel: 6 gobos +white, wheel rotation and shake
Prism:3-facet Prism, bi-directionally rotatable at variable speeds
Feature: Temperature protect function, when the internal Temperature is up to 40° and then the fans begin to work, when the internal temperature is up to 70°and the brightness reduce half.
Efficient low noise fan cooling system
Effect macros:
0%-100% linear dimming
Strobe: 1-25times/second
LCD display screen
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 270 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Two 1/4 turn fastening Omega Clamps
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 450Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 15 Kg(33.07lbs)
Size: 20.47" x13.58" x 10.83" (L52x W34.5 x H27.5)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
High output white led |
|
Power |
1x150W |
|
Lumen |
High light output, 3450LUX@5M at White light |
|
LED life expectancy |
50000Hours,low power consumption |
|
Color Temperature |
7800K |
|
Photometric data |
|
|
Lens angle |
15° |
Product details
