High-Output Light Source: Uses a reliable 260W Japanese Phoenix lamp with a 8000K cold white temperature, ensuring bright, crisp beams ideal for cutting through ambient light.
Adjustable Beam Optics: Features a wide beam angle range (4°–60°) and motorized focus (3.8°–45° linear adjustment), allowing seamless transitions from tight aerial shafts to broad washes.
Rich Effect Options: Includes a 13-slot color wheel (with rainbow effect), a 13-slot pattern wheel, a rotating 8-facet prism, a 24-facet honeycomb prism, a frost filter, and a dedicated rainbow lens—enabling diverse visual textures and dynamic looks.
Flexible Control & Protection: Supports DMX512, sound activation, master-slave, and manual operation via an 18-channel mode. Integrated features like mechanical/speed-adjustable strobe, strobe macros, auto-reset, and overheat protection ensure safe, consistent performance.
Smooth Movement & Durability: Provides 540° horizontal and 270° vertical pan/tilt with precise scanning. Built to IP20 standards for indoor use, with optional flight case packaging for transport protection.
Conclusion
Choose this 260W Beam Moving Head if you need a reliable, feature-rich lighting fixture that excels in beam effects, color mixing, and pattern projection. Its combination of a quality lamp source, wide zoom range, multiple prism and color options, and flexible control modes offers strong value for entertainers, venue owners, and event producers looking to enhance visual impact without compromising on usability or durability.
Personalities
DMX Channel: 18CH
Protocols: DMX
Colors:
Color wheel: 13 color plus open
Gobo wheel: 13 pattern plus open
Prism lens: 12+24 dual lens
Feature: standard additional lens is rainbow lens
Effect macros:
0%-100% linear dimming, smooth without flicker
Strobe: 0-25Hz
LCD display screen
Motor: The XY axis uses a three-phase motor, which ensures high speed stability and accurate positioning angle of the lamp!
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 270 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 450Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 18 Kg(39.68lbs)
Size: 17.72" x16.93" x 22.44" (L45 x W43 x 57H)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
Japan Phenix bulb |
|
Power |
1x260W |
|
Ballast |
Electronic ballast |
|
LED life expectancy |
4000Hours(The bulb and reflector are packaged as a whole, with higher light efficiency and longer service life) |
|
Color Temperature |
8000K |
|
Photometric data |
|
|
Lens angle |
4-60° |
Product details
