This is where the light shines:
Color: A 13-color wheel + open allows for instant color changes.
Patterns: 14 static gobos for projecting fixed logos and textures, plus 9 rotating gobos for dynamic, moving patterns.
Prisms & Diffusion (Key Feature): The unique 3-in-1 Effect Wheel combines an 8-facet rotating prism, a 6-row linear prism, and a frost lens. This enables stunning multi-beam splits, geometric distortions, and soft beam blending—tripling the effect possibilities from a single wheel.
Superior Output & Quality: The genuine OSRAM lamp ensures brighter, more consistent light and longer lifespan than generic alternatives.
Unmatched Versatility: From solid colors and complex gobos to dazzling prism effects, it replaces multiple specialized fixtures.
Professional Smoothness: 16-bit movement ensures cinematic-quality pans and tilts, crucial for professional productions.
Operational Reliability: Overheat protection safeguards the investment. Mechanical dimming eliminates low-end flicker.
User-Friendly: Clear display, tactile buttons, and auto-run modes make setup and operation straightforward.
Personalities
DMX Channel: 16/24CH
Protocols: DMX
Colors:
Color wheel: 13 color plus open
Fixed Gobo wheel: 14 pattern plus open
Rotate Gobo: 9 pattern plus open
Effect wheel:one Rotation eight prism+ one Rotation six row prism lens + frost lens
Amazing dot matrix, four tact switches, 180° turning show 280W beam spot
Lens optical system focus
Effect macros:
0%-100% linear dimming, mechanical dimming, and free dimming available.
Strobe: strobe macro control available
LCD display screen
Motor: The XY axis uses a three-phase motor, which ensures high speed stability and accurate positioning angle of the lamp!
Pan:540 ° rotation, resolution 8/16 bit, with fine tuning
Tilt: 270 ° rotation, resolution 8/16 bit, with fine tuning.
Housing
Aluminum die cast
Two side handles for transportation
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 420Watt
Packaging
Carton box + Foam shell
Flight case + Foam shell
Weight - size
Net Weight: 20 Kg(44.09lbs)
Size: 23.62" x18.11" x 18.9" (L60x W46 x 48H)
Product display
Application scenarios
Product specification
|
Light source |
|
|
Source type |
Osram bulb |
|
Power |
1x280W |
|
Ballast |
Electronic ballast |
|
LED life expectancy |
5000Hours(The bulb and reflector are packaged as a whole, with higher light efficiency and longer service life) |
|
Color Temperature |
7800K |
|
Photometric data |
|
|
Lens angle |
3.8°-45° |
Product details
