(High Output & Optical Superiority): The 600W LED engine coupled with the large 180mm diameter front lens ensures a powerful, intense beam with excellent clarity and throw distance, providing a superior alternative to traditional discharge lamps without sacrificing output.
(Professional Color Mixing & Effects): The linear CMY color mixing system offers infinite, smooth color transitions and subtle pastel shades, while the independent 5-color wheel provides instant access to bold, saturated colors. This dual system enables rapid color changes and complex layered looks, a key advantage for dynamic live performances.
(Dynamic Gobo & Texture Engine): With two gobo wheels (6 static + 7 rotating), a rotating 4-facet prism, and frost filters, the fixture can create a vast library of textures, patterns, and multiplied beam effects. The rotatable prism and gobos add remarkable depth and motion.
(Industry-Leading Framing/Beam Shaping System): This is the defining competitive advantage. The 8 independently controlled framing shutters, each with adjustable position and angle, plus ±60 degrees of system rotation, grant pixel-level precision for shaping light into squares, triangles, slices, or any custom shape. This is crucial for architectural highlighting, isolating performers, or creating stark visual compositions.
(Reliability & Control): The 34-channel mode offers detailed parameter control. Flicker-free management guarantees perfect camera compatibility for broadcast events. The dust-proof and oil-proof design enhances longevity and reliability in challenging environments.
Colors: Linear CMY color mixing
Effect macros: Static effect macro function and dynamic effect macro function
Wash: evenly spread light at medium to large angles
Zoom system: linear electric zoom
4 facet prism with bi-direction rotation Optical.
Iris:Motorized linear
Framing:the framing module can rotate at ±60 degrees
Tilt: 270°
Pan: 540°
Color wheel: 5 colors + open
Rotation gobo wheel: 7 gobos + open
Static gobo wheel:6 gobo+open
Frost: With frost to make soft wash effect
0-100% linear dimmer
Focus: Electric focus
Strobe: 0-25Hz with multi strobe effects
Hardware and software
2.80 inch LCD display screen
Channel data and software version failure information
Software upgrade: Upload upgrade files through DMX
It allows users to switch freely between Chinese and English, and the font can be automatically rotated 180 degrees.
Housing
Dust-proof and oil-proof design
Two side handles for transportation
IP20 protection rate
Working in any position
Hanging system: with fast lock Omega clamps
Electrical
Optical voltage: AC100-240V,50/60 Hz
MAX power consumption: 600Watt
Safety Specification
Protections:
Temperature control: Intelligent temperature control, capable of automatically adjusting the speed of the cooling fan and overheating protection, with three fan modes
Product specification
|
Light source |
|
|
Source type |
1x600W white LED |
|
Power |
600W |
|
Color Temperature |
2500K-10000K |
|
LED life expectancy |
20000 hrs |
|
*It may vary depending on various factors, such as the type of use and environment |
|
|
Photometric data |
|
|
Zoom Range |
7°-42° |
| Front Lens |
180mm diameter
|
|
Packaging |
|
|
Carton box + Foam shell |
Flight case + Foam shell |
|
Weight - size |
|
|
Net Weight |
25.6 Kg(56.44lbs) |
|
Size |
32.68" x20.08" x 16.54" (L83 x W51 x H42) |
Control and connections
|
Personalities |
|||
|
DMX Channel |
34CH |
Connectors |
Locking 3 / 5 pin XLR IN/ OUT |
|
Protocols |
DMX ,RDM |
Power connector |
PowerCon IN/OUT |
application Scenarios
